5157/5157 ACL S-Series DLT Subsystems Installation Users Guide
Operating the 5157 ACL Tape Drive 6-16
Note: If the message ‘Magazine Locked’ appears on the screen, the host
software has locked the magazine. Exiting the backup or HSM software
usually will release the lock. In the event of host failure, it will cycle the
power to the 5157 ACL to release the lock.
6.10.3 Show Status Menu
Note: The Show Status submenu can be selected directly from the
Default Screen without entering the Menu Mode by pressing the
Escape button. In this way, status can be checked at any time
without interrupting host operations.
When Show Status is selected, either from the Main Menu or from
the Default Screen, the submenu shown in Figure 6-11 appears.
÷ ÷Library Library
DLT 1 DLT 1
Map Info Map Info
Figure 6-11 Show Status Menu
The items available on the Show Status menu are:
•
Library
•
DLT1
•
Map Info.
Move the ÷ up or down with the ù and ü buttons, then press the
Enter button to select the item.
