8 Monitoring the system
Monitoring pairs, journals, data paths, I/O, and hardware performance is crucial for ensuring
that Continuous Access Journal Z pairs continue to function correctly.
This topic provides information and instructions for monitoring a Continuous Access Journal Z
system.
Monitoring pair activity and status
Monitoring the Continuous Access Journal Z system is essential for maintaining your pairs.
•
Each operation requires a specific status or statuses. Before performing a pair operation,
check the pair’s status.
•
Pair status changes when an operation is performed. Check status to make sure that pairs are
operating correctly and that data is updated from P-VOLs to S-VOLs, and that differential data
is managed appropriately.
Frequent monitoring of the system is optional but recommended. You can set up automatic e-mail
notification from the RWC for problems found during monitoring (see HP P9000 Remote Web
Console User Guide).
Procedure 17 To monitor pair activity
1. In the Remote Web Console main window, click Actions > Remote Copy > Continuous Access
Journal Z > Pair Operation.
2. In the Pair Operation window, locate the pair whose status you want to review and check its
status in the Status column.
3. To filter the list, click Display Filter. Headings are described in “Display Filter dialog box ”
(page 178) and the Help.
4. To export pair information, see “Saving pair information to a text file ” (page 86) .
5. To view more detailed pair information, right click a pair and then select Pair Status from the
menu.
Pair status definitions
Both Remote Web Console and Business Continuity Manager pair status names appear in the
Remote Web Console Status columns, except when the names are the same. When they are the
same, the Business Continuity Manager status does not appear.
The following table shows both types of status names and their descriptions. In some cases, a
particular status has no exact parallel status in the other interface. This is noted.
When checking your pairs’ status, click File/Refresh to make sure the data is current.
S-VOL access P-VOL
access Description BCM status RWC status
Read/Write Read/Write The volume is not assigned to a pair and is not in a journal. SIMPLEX Simplex
•
When the volume is added to a pair, the status changes
to Pending.
• When a pair is released, the volumes’ status changes
back to Simplex.
If a pair is released from the secondary system, S-VOL
status changes to Simplex; when the primary system
detects this, P-VOL status changes to Suspend. The pair
must be released from the primary system also to change
P-VOL status to Simplex.
No Read/Write The initial copy operation is in progress. PENDING (01) Pending
