Description Item
•
Underflow or Overflow appears in this column if an invalid time stamp is detected. If
Underflow appears, the time stamp is below the allowable range. If Overflow appears, the
time stamp is above the allowable range.
•
The consistency time is valid only for the updates on the Cnt Ac-J Z pairs in Duplex status.
When the data of the Cnt Ac-J Z pair that is in other than Duplex status is updated, the
consistency time is not assured. Therefore, even if the journal of the Cnt Ac-J Z pair that shares
the volume with BC Z or Cnt Ac-S Z is registered to the EXCTG, the consistency time is invalid
if the Cnt Ac-J Z pair is in other than Duplex status or if the BC Z or Cnt Ac-S Z pair is updated.
The consistency time is invalid also when the data is updated without the time stamp from
the host computer.
The number of systems registered in an EXCTG. Num of DKC
The number of journals registered in an EXCTG. Num of JNL
View systems in an EXCTG
To display systems in an EXCTG
1.
Display the EXCTG Operation window.
2. In the tree, double-click Registered, then double-click the desired serial number that displays
below Registered. Associated EXCTGs display in the tree below the selected LDKC.
3. Select the desired EXCTG.
Fields in the system list are described in the following table.
Description Item
Serial number of a system and LDKC number that is enclosed by parentheses. S/N(LDKC)
Controller ID of a system and the model name of a system that is enclosed by parentheses. Controller ID
Journal number, which is a three-digit hexadecimal number. JNL
Mirror ID, which is a two-digit hexadecimal number. Mirror ID
Remote command device. The number on the left of the colon (:) is a CU number. The LDKC
number, the CU number and the LDEV number are displayed. Cmd. Dev.
View journals in an EXCTG
To display the journals in an EXCTG
1.
Display the EXCTG Operation window.
2. In the tree, double-click Registered, then double-click the desired serial number that displays
below Registered. Associated EXCTGs display in the tree below the selected LDKC.
3. Select the desired EXCTG in the tree. Associated systems then display in the tree.
4. Select the system you want.
Fields in the system list are described in the following table.
Description Item
Journal numbers. A journal number is a three-digit hexadecimal number. JNL
Mirror ID of a journal. Mirror ID
The attribute of a journal Attribute
: A master journal.
: A restore journal.
Status of a mirror. Status
