Description Item
Initiator port
External port
Port in initiator/external mix mode
The ports on the local system: Operation
•
Port: Port number.
• Attribute: Port attribute (i.e., initiator, target, RCU target, or external).
•
PCB Mode: Mode of the port. The mode is either Standard or High.
• Error Code: An error code.
DKC Status dialog box
Use this dialog box to view status and other information about the logical path.
Description Item
Number of the row. No
Status of a logical path. Path Status
• Normal. The path is established and ready to use for copy operations.
•
In Progress. An operation for configuring or deleting the path is in progress.
•
Initialization Failed. An error occurred when the connection between local and remote
systems was initializing. The probable causes are:
- No cable is connected to the local system.
- No cable is connected to the remote system.
- No cable is connected to the network device between the two systems.
DKC Operation window 183
