Description
Item
Indicates the journal’s function in a Cnt Ac-J Z 3DC cascade configuration. This option can
be specified when only the unused journal is specified. Cannot be used together with the
2DC cascade configuration.
Cnt Ac-J MF 3DC
Number of the selected journal. A journal number ending in [M] indicates the journal is in a
3 Cnt Ac-J Z DC configuration; for example, 001 (00) [M].
Journal
Number and the capacity of journal volumes currently in the journal.
Current
Estimated number and the capacity of journal volumes after addition or deletion.
Total
Pair Operation window
Use this window to view the pairs for the selected port or host group:
You can perform these procedures from the window:
•
“Creating the initial copy ” (page 68)
•
•
•
Description
Item
Lists LDKCs of the local system, with CU groups displaying under the LDKC. The CU images appear under
the CU groups. Selecting a CU group or a CU image lists the volumes for the CU group or image. You
can select only one CU group or image at one time and cannot select two or more simultaneously.
Tree
When clicked, opens the Display Filter dialog box where you can filter information in the Pair Operation
list. See
“Display Filter dialog box ” (page 178)
for more information.
Display Filter
Saves information about volume pairs in a text file.
Export
Shows the next or previous listing of pairs.
Previous/Next
Pair Operation window
167
