Description Item
Indicates a primary volume (P-VOL). The numbers are the LDKC number, the CU number and
the LDEV number of the P-VOL. P-VOL
This column displays only one P-VOL even when two or more P-VOLs are selected in the Pair
Operation window. P-VOL only displays the P-VOL that has the smallest volume number.
An LDEV ending with # indicates the volume is an external volume.
Secondary volume. For information on selecting an S-VOL, see “Creating the initial copy ”
(page 68)
S-VOL
When multiple pairs being created, sets S-VOLs for other P-VOLs. Select Other S-VOL(s)
For information on selecting multiple S-VOLs, see “Creating the initial copy ” (page 68)
Mirror for the pair. Consists of the pair’s master and restore journals, and a mirror ID. Mirror
• M-JNL: The pair’s master journal.
•
Mirror ID: The identifier for the mirror.
• R-JNL: The pair’s restore journal.
Journal numbers used by Cnt Ac-J do not display in R-JNL; only the journal numbers for Cnt
Ac-J Z display.
The consistency group number displays. Registered consistency groups have an asterisk (*).
An asterisk also displays if the consistency group is in the Preview list. CT Group
The serial number with the number of LDKC and the controller ID with the model name of the
secondary system. This option also allows you to specify the ID (Path Gr. ID) and path type DKC
(channel type). The secondary system must be the same for all pairs being created during one
operation.
174 GUI reference
