HP XP P9500 Storage - Manual (Page 130)

SVP log file System generating the
SIM Description Severity Reference code
Byte 23 Byte 22
SIM Log Primary A volume used in a P-VOL that is
configured in a multiple primary and Serious AX DC
secondary system combination has been
suspended.
A failure has been detected in other
primary and secondary systems.
Notes:
If the DKC emulation type is 2105 or 2107, the setting of system option mode 308 determines whether the SIM is reported to
the host, as explained below:
•
When system option mode 308 is set to ON, the SIM is reported to the host.
•
When system option mode 308 is set to OFF, the SIM is not reported to the host. By default, system option mode 308 is set
to OFF.
Enabling or disabling SIM reporting
You can enable or disable the reporting of SIMs to the host.
Procedure 35 To enable or disable SIMs reporting to the host
1. In Remote Web Console click Actions > Remote Copy > Continuous Access Journal Z > Optional
Operation.
2. Click to change the mode from View to Modify.
3. Select LDKC in the tree. The list displaying on the right-side shows whether or not SIMs are
reported.
4. You can change the SIM reporting setting for all CUs, or for one CU.
•
To change the setting for all CUs, right-click LDKC in the tree and select Change SIM
Report.
•
To change the setting for one or more (but not all) CUs, select one or more CU in the list
on the right-side pane, right-click, and select Change SIM Report.
5. The changes you made display in the Preview list. To delete a change, right-click and select
Delete. When you right-click the Preview list, the Modify command is not available.
6. Click Apply when ready.
To see information about any error during this operation, right-click the error code and then select
Error Detail. An error message appears with information about the error.
Clearing SIMs
SIMs that are sent to hosts are also saved in the system. The following procedure clears all SIMs
from both mainframe and open systems:
CAUTION: When you delete Continuous Access Journal Z SIMs, the SIMs for Continuous Access
Journal for open systems are deleted also. The SIMs of the entire system are cleared.
Procedure 36 To clear all SIMs
1. In Remote Web Console, click Actions > Remote Copy > Continuous Access Journal Z > Optional
Operation.
2. Click to change the mode from View to Modify.
3. Click Clear SIM in the upper right corner of the window.
4. A message appears asking whether to delete SIMs. Click Yes.
130 Troubleshooting
