Storage Mirroring Ports
Both the Management Console and the Storage Mirroring server use ports to communicate with each other.
Management Console ports
The Storage Mirroring Management Console uses two ports for Storage Mirroring communications.
Heartbeat Port
—The Management Console uses this port to listen for heartbeats transmitted from Storage Mirroring
servers.
Status Transmit Port
—The Management Console uses this port to send requests to Storage Mirroring servers so that
it can update its at-a-glance monitoring information.
1.
To access the port settings, select
File
,
Options
.
2.
Under Storage Mirroring on the
Configuration
tab, modify the
Status Transmit Port
and specify the number that you
want to assign to the port. Under Automatic Service Discovery on the
Configuration
tab, modify the
Heartbeat Port
and specify the number that you want to assign to the port. The default values are
1505
and
1500
, respectively. The valid
values are
1025
to
65535
.
3.
Click
OK
to save the settings.
NOTE:
These changes will add any new Storage Mirroring machines to the display, but will not remove Storage
Mirroring machines that are using the previous port settings. To remove those machines, the Management
Console must be restarted.
