88
PP-32
KOOLMASTER PP-32
REV.01
A test mode allows you to simulate temperature changes and verify
the controller's performance. In test mode, the temperature sensor inputs
are turned off, allowing the user to change the temperature used by the
controller to operate the stages. The controller operates as before using
the new temperature settings.
Adjusting Room Temperature
When the room temperature is adjusted, the controller bypasses the tem-
perature sensor inputs and uses the new value as a reference. The test
mode is deactivated after 15 minutes of inactivity.
Set the function to "23.Test Mode" from the main menu using the
navigation buttons then press the right-arrow key. The On/Off status
of the test mode displayed.
Press to activate the test mode.
Press the down-arrow key to select
the room temperature.
Use the adjustment buttons to set the
room temperature to the desired
value.
The controller then displays the fan stage that is activated, in accordance
with the selected temperature. It also displays the current program in use
and the static pressure readings (if a static pressure sensor is used). These
values are displayed as readings, they cannot be modified.
5.15.5 Test Mode
Test Mode
Mode On
Temp: 69.5 °F
Static Pressure .015
Fan Stage: Min.V
Program: (a)
