5.2 CONTROLLER PROGRAMS
The controller allows to use up to 4 separate programs to control the
room temperature. It then becomes possible to activate a specific
program, that uses particular fan settings, in accordance with the animal
age for instance.
Relays that are activated on fan stages 1-4 vary depending on the chosen
program: the first 4 fan stages use separate relay assignment settings for
each program. This allows to activate a greater number of fans as the
occupied space in the barn increases. Fan stage's sensor assignment must
also be set separately for each program in use.
5.2.1 Selecting a Program
Use the navigation buttons to select
"5. Program Select" from the main
menu then press the right-arrow
key. The program that is currently
in use is flashes on the display.
Use the adjustment buttons to select
the proper program (a, b, c or d).
Only the programs that have been
enabled during the installation can be
selected (see sec. 5.14.3). Press the
left-arrow key to exit this menu.
5.2.2 Selecting a Season
The start and stop temperatures of heating and ventilation stages can be
set separately for summer and winter seasons. The season change is
signalled by the user as follows:
Use the navigation buttons to select "5. Program Select" from the
main menu then press the right-arrow key. The program that is
currently in use is flashes on the display.
Press the down-arrow key to select the " Temp Settings" display.
Fan / Sensor Program
Selection: (a)
Temp Settings: Summr
Main Menu
5. Program Select.
