Acme PP-32 - Manual (Page 79)

79
PP-32
KOOLMASTER PP-32
REV.01
Note that the temperature curve must be turned off to adjust
its points and days. Use the down-arrow key to scroll each point
of the curve. The curve status then flashes on the display. Use
the adjustment buttons to turn it Off.
Set the function to "6.Room Set
Point" from the main menu then press
the right-arrow key. The current set
point and the curve status are dis-
played.
Press the down-arrow key once. The
first day, corresponding to the first
point of the curve flashes on the dis-
play.
Use the adjustment buttons and set the first day of the curve to the
desired value.
Press the down-arrow key once again. The temperature for the first
point of the curve flashes on the display.
Use the adjustment buttons to adjust the temperature for the first
point of the curve to the desired value.
Press the down-arrow key to display and adjust all other points of
the curve.
Once they are all properly set, press the down-arrow key. The curve
state flashes on the display. Press
to activate the curve.
NOTE: All ten points of the curve must be specified. If ten points are not
needed, repeat the last temperature value for each unnecessary point.
Room Set Point
Temperature
Set Point: 70.0°F
Curve stat Off
Room Set Point
Temperature
Day: 1
Temp: 78.0°F
