87

PP-32

KOOLMASTER PP-32

REV.01

Use the adjustment buttons to set the humidity level that will be

added or removed from all readings of the humidity sensor.

5.15.4.3 Calibrating the Static Pressure Level

The reading of the static pressure level can adjusted by an amount of

±0.030"WC (±7Pa).

Select "8.Vents/Static P" from the

main menu using the navigation

buttons then press the right-arrow

key. The calibration menu flashes

on the display "Cal. SP". Note that

this menu is only available if the

static pressure sensor has been enabled during the installation setup

and in the installer mode (see sec. 5.14.2 and 5.14.3).

Use the adjustment buttons to set the humidity level that will be

added or removed from all readings of the humidity sensor.

Vents/Static Press

Cal. SP .000”WC

Close At: .070”WC

Open At: .090”WC
