22
PP-32
KOOLMASTER PP-32
REV.01
Inlet Compensation
Inlet 1 5%/°F
Inlet 2 5%/°F
Inlet 3 5%/°F
Note that the reference numbers that
are used by the PP-32 DO NOT
correspond to the ID numbers that
used by the DWR-F-1A modules
because #1, 2 and 3 are reserved for
other purpose.
5.5.1.2 Adjusting the Air Inlet Compensation
The compensation is expressed as a percentage per degree difference
between the average controller's temperature and the average tempera-
ture of sensors that are assigned to the inlet. It determines by how much
the inlet must open or close to help reduce the temperature differences
in the building. For each degree above or below the average tempera-
ture, the inlet will open or close using the compensation value assigned
by the user. For example, if the compensation value is set to 5%/°F and
the inlet's sensors read 3°F above the average controller temperature,
the inlet will open of 15% to help decrease the temperature in that zone.
The compensation can be adjusted from 0 to 10% of inlets' opening or to
"Off" to deactivate this function.
Select "8.Inlet Settings" from the main menu using the navigation
buttons then press the right-arrow key. Note that this menu is only
available if the static pressure sensor is disabled and if inlets have
been activated (see sec. 5.15.3).
Press the right-arrow key once
again to select "1.Inlet Comp"
menu. The compensation value of
each air inlet is displayed.
Use the up or down-arrow key to
select the desired inlet.
Use the adjustment buttons to set
the compensation to the proper
value. Press the left-arrow key to
exit this menu.
2 3 - P P
# e c n e r e f e R
# d i A 1 - F - R W D
1 4
2 5
. . . . . .
2 1 5 1
Inlet Settings
1. Inlet Comp
