15

KOOLMASTER PP-32

REV.01

5. CONTROLLER SETUP

5.1 CURRENT CONDITIONS

The current conditions menu gives a quick view of the actual conditions
in the barn. Press

to step directly to this menu.

Room Set Point: this is the target

temperature in the barn.

Average Temperature: shows the

average temperature in the barn.

Static Pressure: current static pressure

in the barn.

Fan Stage: shows which fan stage is

currently active.

Program: shows the selected program.

Fan On-Time sec: fans' on-time in minimum ventilation.

Sensor 1-8: actual reading of each temperature sensor.

Outside: actual outside temperature reading.

RH Sensor: current humidity level in the room.

Room Set Point 80.0

Average Temp 79.2

Static Pressure 0.01

Fan Stage: Min.V

Program: (a)

Fan On Time sec 30

Sensor 1: 79.3

Sensor 2: 79.1

Outside: 65.9

R. Humidity 74
