Stage 1a Relays:
Relay 1 On(1)
Relay 2 Off(1)
Relay 3 Off(1)
5.14.6.1 Assigning Fan Stages' Relays
Ventilation stages 1 to 4 use a separate relay assignment for each
progam in use. Refer to sec. 5.2 to select the proper program.
MAKE SURE EVERY FAN STAGE HAS RELAYS ASSIGNED TO IT!
An alarm is set off whenever a fan stage, that doesn't activate
any relay, is activated. In this case, all relays of the previous fan
stage are copied into this stage.
Set the function to "17.Fan Settings" from the main menu using
the navigation buttons then press the right-arrow key. Note that this
menu is only available in the installer mode (see sec. 5.14.2).
Press the right-arrow key once again to select the "1.Relays" menu.
Use the adjustment buttons to
select the proper fan stage then
press the right-arrow key. The
letter that stands beside stages 1-4
corresponds to the current program
in use (if applicable).
Use the up and down-arrow keys to
select the desired relay. When the
item is flashing, press
to activate
the relay or to deactivate it.
Proceed in similar fashion to assign relays for each fan stage.
TIMER RELAYS ON FAN STAGES:
The user can configure certain relays to operate in timer mode for
cooling while other relays operate in ON/OFF mode. For example, a Kool-
Cel Pump can operate according a timer mode, using a fan stage output.
The Kool-Cel Pump will then operate while fan stages continue running at
the same time. Timer relays can only be set on fan stage outputs. Refer
to section 5.7.2 to set the timers' ON and OFF time settings.
Ventilation Stage
Relay Assignment
3. Stage 1a
4. Stage 2a
!
