Page 74

PP-32

KOOLMASTER PP-32

REV.01

Use the navigation buttons to select the "2. Relay Settings" menu

then press the right-arrow key.

Use the navigation buttons to select the "1.Open Relay" or "2. Close

Relay" menu then press the right-arrow key.

Use the right and left-arrow keys to

select the desired relay. When the
item is flashing, press

to activate

the relay or

to deactivate it.

5.14.6.4 Assigning Relays to the Tunnel Curtain

Relays 13-14, 15-16, 29-30 and 31-32 have specially been designed for

vent doors, air inlets or tunnel curtain. It is strongly recommend to use

these relays to open/close these devices: this prevents activating the

OPEN and CLOSE relays, by inadvertence, at the same time.

ASSIGNING CURTAIN'S OPEN / CLOSE RELAYS:

Set the function to "9.Tunnel Curtain" from the main menu using

the navigation buttons then press the right-arrow key. Note that this

menu is only available in the installer mode (see sec 5.14.2) and if

the tunnel curtain has been enabled during the installation setup (see

sec. 5.14.3).
