Acme PP-32 - Manual (Page 75)

75
PP-32
KOOLMASTER PP-32
REV.01
Clock 1 Relays
13 14 15 16 17 18 19
√
Auxiliary 1 Relays
13 14 15 16 17 18 19
√
5.14.6.5 Assigning Relays to Clock Outputs
Set the function to "11.Clock Times" from the main menu using
the navigation buttons then press the right-arrow key. Note that this
menu is only available in the installer mode (see sec. 5.14.2) and if
clock outputs have been enabled during the installation setup (see
sec. 5.14.3).
Use the navigation buttons to select the "2. Clock Relays" menu then
press the right-arrow key.
Use the navigation buttons to select the desired clock output then
press the right-arrow key.
Use the right and left-arrow keys to
select the desired relay. When the
item is flashing, press
to
activate the relay or to deacti-
vate it.
5.14.6.6 Assigning Relays to Auxiliary Outputs
Set the function to "17.Fan Settings" from the main menu using
the navigation buttons then press the right-arrow key. Note that this
menu is only available in the installer mode (see sec. 5.14.2) and if
auxiliary outputs have been enabled during the installation setup (see
sec. 5.14.3).
Press the right-arrow key to select the "1.Relays" menu.
Use the navigation buttons to select the desired auxiliary output then
press the right-arrow key.
Use the right and left-arrow keys to
select the desired relay. When the
item is flashing, press
to activate
the relay or to deactivate it.
