Press the down-arrow key to select the Hi alarm limit.
Use the adjustment buttons to set the Hi alarm limit to the desired
value.
Note : If you do not want a relay to be turned off in the case of a low
static pressure alarm, set the Low Alarm limit to " Off" by
pressing the down-arrow key.
Adjusting High/Low Delays
Set the function to "21.Alarm Limits" from the main menu using the
navigation buttons then press the right-arrow key.
Use the navigation buttons to select "2.Static Pressure" then press
the right-arrow key.
Press the right-arrow key once again in order to select the "1.Hi/Lo
limits" option. The Lo and Hi pressure limits are displayed.
Press the down-arrow key in order
to select the "Lo Delay" display.
Use the adjustment buttons to set
the Lo Pressure Alarm Delay to the
desired value.
Press the down-arrow key once again to select the "Hi Delay" display.
Use the adjustment buttons to set the Hi Pressure Alarm Delay to
the desired value.
Low Alarm .030”WC
Hi Alarm .150”WC
Lo Delay 60sec
Hi Delay 300sec
