6.5.3
Relay 1 Output
Scroll to “
RELAY1 OUTPUT
” from
“INTERFACE
” using the
▲▼
keys and press ENTER.
Use the
◄►
keys to enable or disable Relay 1 output.
The configuration of the Relay 1 Output should be set under the output configuration menu. Refer to
section (6.4.2) for more details.
Relay 1 is mapped to alarm high and will be affected by the alarm settings under the system setting
menu. Refer to section (6.2.8) for more details on alarm activity.
A prompt will be shown to set this value as a default setting.
Whenever the Relay 1 Output is enabled a check mark showing that this feature is enabled will be seen
on the display.
WOULD YOU LIKE
TO SAVE AS
DEFAULT?
SELECT DESIRED
ACTIVITY
USING
◄,► KEYS
[ENABLE]
USB OUTPUT¾
ASCII OUTPUT
►
RELAY1 OUTPUT
RELAY2 OUTPUT
