6.4.1 Digital ASCII
Scroll to “ DIGITAL ASCII ” from “ OUTPUT CONFIG ” using the ▲▼ keys and press ENTER.
ASCII output consists of four rows of data. Each row can be separated using following options:

Carriage Return: carriage return (CR) is one of the control characters in ASCII code which moves
the position of the cursor to the first position on the same line

Line feed: moves the cursor on a display screen down one line.

Carriage Return and line feed: moves to the next line, while carriage return precedes line feed to
indicate a new line.

Line feed and Carriage Return
Use the
◄► keys and press ENTER to select CR, LF , LF & CR or LF & CR .
WOULD YOU LIKE
TO SAVE AS
DEFAULT?
SELECT DESIRED
TERMINATION CHAR
USING ◄,► KEYS
[CR+LF]
► DIGITAL ASCII
ALARM RELAY1
ALARM RELAY2
VOLTAGE CONFIG
