6.1.3.2 Direction
Scroll to “ DIRECTION ” from “ NEW CHANNEL ” using the ▲▼ keys and press ENTER. “ DIRECTION ”
can also be selected from “ EDIT CHANNEL ” to make modifications on the existing channels except
channel one.
Using the
◄► keys on the keypad select either uni-direction or bi-direction.
OPERATION
WAS EXECUTED
SUCCESSFULLY
(HIT ENTER/BACK)
► DIRECTION
UNIT SELECTION
SENSOR CAPACITY
SENSITIVITY(+)
SELECT DESIRED
DIRECTION TYPE
USING ◄,► KEYS
[UNI-DIRECTION]
