9 Appendix C (Device Specifications)
Main Control Processor Unit (MCPU)
Part #:
MSC1214 (Elite Version)
Internal ADC Resolution: 24 bits
Sampling Rate: 60 SPS
Application: Diagnostic mode
DAC Resolution: *
16 bits
DAC Accuracy: * 0.02% of FSR (Factory Calibrated)
DAC Non linearity:* 0.1% of FSR (Factory Calibrated)
Application:* Voltage output/ Current output
Analog to Digital Converter (ADC)
Part #:
AD7190
Recommended Load: 30 to 30000 Ω
Bridge Excitation: 5.000 V ± 1 mV (limited current to 160 mA)
Input Range: ±2.5 V (0-500mV/V) Channel 1 for bridge
Input Range: ±12 V Channel 2 for Voltage/Current input
Sampling rate: up to 4800 SPS
Non linearity: ± 5 PPM for FSR
Offset Drift vs. temperature: ± 5 PPM/°C
Span Drift vs. temperature: ± 5 PPM/°C
Application: Signal measurement
Voltage Reference
Part #:
MAX6126AASA25+
Accuracy: ± 0.02%
Nominal Voltage: 2.5 V
Temperature Shift: ± 3 PPM/°C
Application: Reference Voltage / Excitation voltage
Power Requirement
Internal battery: Rechargeable, lithium polymer battery
Battery size: 7.4 V/ 3000 mAh
Run Time: up to 30 hours with 350Ω Bridge
Battery Charger: Wall plug AC powered-unit
Battery Charger Output: 12 V/ 1 A
Battery Indicator: 0-100%, 0-8.5 V
Battery Warning: Less than 20%
Run Time: Up to 30 hours (350 Ω Bridge connected)
