It is important to know that IHH500 is equipped by a high speed Processor.
This processor is responsible to control every single feature of device and dedicates the specific time
frame for internal operation and Interfaces.
During a high speed data logging session (600, 800, 960, 1200, 1600, 2400 and 4800) the Voltage output,
Current output, and ASCII output are internally disabled and the data logging menu cannot be left until
the timer expires. This will force the processor to allocate more time frames to process the data from
ADC, perform the calculation, and save the data into the internal buffer, however after completing the
data logging session, the initial conditions will be restored.
When performing data logging session at lower speed sampling rates below 600 sps, there is an option to
exit the data logging screen and return to the main screen where the countdown timer shows the elapsed
time.
The following message will be displayed as soon as the data logging session has been completed.
DATA LOGGING
PROCESS IS
COMPLETED
SUCCESSFULLY
+3.03461 Peak
+3.03460 mV/V
+1.59484 Valley
D.L.T. 12.5 S
HIGH SPEED
DATA LOGGING
IN PROGRESS
PLEASE WAIT
