For rotary torque sensors, the following screen will be displayed before returning to the main screen.
NOTE: To monitor Torque, Speed, Angle, and Power on the SENSIT Test and Measurement software
during live graphing, the screen of IHH500 should be changed by pressing the “DISPLAY” key. The
following screen will be displayed:
If an incorrect unit (other than torque) has been selected for a rotary torque sensor, an error message will
be displayed on the last row.
Note: When a torque sensor is configured, the HOLD and SHUNT keys are disabled on the main page
showing the speed, angle and torque. Using the HOLD and SHUNT keys will prompt a warning
message.
+60000 RPM
+400 N-m
+1800 DEG
INVALID UNIT
+60000 RPM
+400 N-m
+1800 DEG
+2513.27 KW
