6.1.3.10.4 Alarm Limit High
Scroll to “ ALARM LIMIT HI ” from “ LIMIT(S) & THD(S) ” using the ▲▼ keys and press ENTER.
Use the arrow keys to move the cursor among the digits and select the desired number for the Alarm
Limit High. The sign value can also be changed from positive to negative in case a bi-directional sensor is
configured.
A confirmation message will be displayed confirming operation was successfully executed.
(See Figures no. 4 and 5 on page 55 for examples of alarm threshold levels for one directional and two
directional sensors ).
OPERATION
WAS EXECUTED
SUCCESSFULLY
(HIT ENTER/BACK)
SELECT DESIRED
VALUE
USING ARROW KEYS
[+120.00%]
FIRST VY THD
MIN / MAX DIFF
► ALARM LIMIT HI
ALARM LIMIT LO
