6.1.3.3.2 Torque
Scroll to “ TORQUE ” from “ UNIT SELECTION ” using the ▲▼ keys and press ENTER. The following
options for torque can be selected: g-mm , g-cm , g-m , kg-cm , kg-m , N-mm , N-cm , N-m , kN-m , in-oz , in-
lb , and ft-lb. Once the desired torque unit is selected, the following message will be shown.
Note: When a torque sensor is configured, the HOLD and SHUNT keys are disabled on the main page
showing the speed, angle and torque. Using the HOLD and SHUNT keys will prompt a warning
message.
OPERATION
WAS EXECUTED
SUCCESSFULLY
(HIT ENTER/BACK)
SELECT DESIRED
ENGINEERING UNIT
USING ◄,► KEYS
[g-mm]
FORCE (MASS)
► TORQUE
PRESSURE
DISPLACEMENT
