6.1.3.8 Pulse per rotation
Scroll to “ PULSE/ROTATE ” from “ NEW CHANNEL ” using the ▲▼ keys and press ENTER.
“ PULSE/ROTATE ” can also be selected from “ EDIT CHANNEL ” to make modifications on the existing
channels except channel one.
Note: This option is only available for rotary sensors with encoders as defined in sensor configuration
sub-menu (6.1.3.1).
Using the
◄► keys move the cursor to the desired placemen, and use the ▲▼ keys the desired number.
Number of pulse per rotations (PPR) can be defined for either rotary or speed sensors. Up to 9999 pulse
per rotation can be defined.
A confirmation message will be displayed confirming that desired operation was successfully executed.
OPERATION
WAS EXECUTED
SUCCESSFULLY
(HIT ENTER/BACK)
SELECT DESIRED
VALUE
USING ARROW KEYS
[0360]
DIRECTION
CALIBRATION
►PULSE/ROTATE
SERIAL NUMBER
