Solid State Relays *
Part #:
G3VM-2F
Application: Alarm relay 1, 2
Maximum Output Voltage: 250 V (AC or DC)
Maximum Output Current: 120mA
Note: Internally limited and protected to 110 V/100 mA
*Available in Elite Version Only
Liquid Crystal Display (LCD)
Part #:
CFAH1604B-TMI-ET
Brand: Crystalfontz America, Inc.
Number of Characters
(Width):
16 Characters
No. of Lines (Lines): 4 Lines
Backlight Type & Color: T-LED, white
Fluid Type, Image (Positive
or Negative), & LCD glass
Color:
M-STN, Negative, blue
Polarizer Film Type, Wide
(WT) Temperature Range, &
Viewing Angle (O’clock):
I-Transmissive, WT, 6:00
Character Set (CGROM): English and European fonts
Controller: T-Sitronix ST7066U
Mounting detail
2 pin male connector:
99 5101 00 02 IP66
2 pin Female connector: 09 0104 99 02 IP66
4 pin male connector: 99 5109 00 04 IP66
4 pin Female connector: 09 0112 99 04 IP66
8 pin male connector: 99 5171 00 08 IP66
8 pin Female connector: 09 0174 99 08 IP66
12 pin male connector: 99 5129 00 12 IP66
12 pin Female connector: 09 0132 90 12 IP66
Power Output *
Part#:
DCP020515DU, LM2671
Nominal Output1: 24 V / 50 mA
Nominal Output2: 5 V / 50 mA
Application: Excitation for amplified sensors
Response Times
Conversion capture rate:
every sample
