6.4.5 Current Value
Scroll to “ CURRENT VALUE ” from “ OUTPUT CONFIGURATION ” using the ▲▼ keys and press
ENTER to define the current value.
Use the ◄► keys and press ENTER to select any of the following Ranges: 0-20 mA , 4-20 mA , 0-25 mA or
5-25 mA .
A prompt will be shown to set this value as a default setting.
SELECT DESIRED
CURRENT VALUE
USING ◄,► KEYS
[0-20 mA]
ALARM RELAY2
VOLTAGE CONFIG
► CURRENT VALUE
CURRENT CONFIG
WOULD YOU LIKE
TO SAVE AS
DEFAULT?
