6.1.3 New Channel
Scroll to “ NEW CHANNEL ” from the “ SENSOR PROFILE ” using the ▲▼ keys and press ENTER. Use
the ◄► to select the remaining 2 to 15 channels. Press ENTER to set the data for desired channel.
Note: The first channel is already set as default and will be displayed on the screen if no other channel
has been set.
In order to set the new channel data the following steps must be taken exactly in the order in which it is
shown on the screen, the
▼ key cannot be used to skip the steps. If EXIT is pressed while setting the new
channel or editing an existing channel, following warning message will be displayed:
WARNING!
EXIT WITHOUT
SAVING PROFILE?
EXISTING CH(S)
VIEW CHANNEL
► NEW CHANNEL
EDIT CHANNEL
SELECT DESIRED
CHANNEL NUMBER
USING ◄,► KEYS
[02]
► SENSOR CONFIG
DIRECTION
UNIT SELECTION
SENSOR CAPACITY
