TCF Waterside Pressure Drop kPa (20% Ethylene Glycol)
Flowrate l/s
4.0
6.0
8.0
10.0
12.0
14.0
16.0
18.0
20.0
22.0
24.0
26.0
28.0
30.0
32.0
34.0
36.0
38.0
40.0
42.0
44.0
46.0
48.0
50.0
TCF1
1R06S-07
18.9
33.6
51.8
73.5
98.7
127.3
159.5
195.2
234.3
276.9
323.1
372.7
425.8
482.4
542.5
606.0
673.1
743.7
817.7
895.3
976.3
1060.9
1148.9
1240.4
TCF1
1R08S-07
16.2
29.2
45.7
65.4
88.5
114.9
144.7
177.8
214.2
254.0
297.1
343.5
393.3
446.4
502.8
562.6
625.7
692.2
761.9
835.1
91
1.5
991.3
1074.4
1160.9
TCF1
1R06L-1
1
14.0
24.2
36.5
50.9
67.5
86.1
106.9
129.7
154.7
181.8
21
1.0
242.4
275.8
31
1.4
349.1
388.9
430.8
474.8
520.9
569.2
619.6
672.0
726.6
783.3
TCF1
1R08L-08
8.2
14.3
21.7
30.4
40.5
51.8
64.5
78.5
93.8
110.5
128.5
147.7
168.4
190.3
213.5
238.1
264.0
291.2
319.8
349.6
380.8
413.3
447.1
482.2
TCF1
1R10L-10
8.3
14.6
22.4
31.7
42.4
54.7
68.4
83.5
100.2
118.3
137.9
158.9
181.4
205.4
230.9
257.8
286.3
316.1
347.5
380.3
414.6
450.4
487.6
526.3
TCF12R08S-09
8.1
13.9
21.0
29.3
38.9
49.6
61.6
74.8
89.2
104.8
121.6
139.7
159.0
179.5
201.2
224.2
248.3
273.7
300.3
328.2
357.2
387.5
419.0
451.7
TCF12R10S-05
7.8
13.5
20.3
28.3
37.5
47.8
59.3
72.0
85.9
100.9
117.1
134.5
153.1
172.8
193.7
215.8
239.0
263.5
289.0
315.8
343.7
372.9
403.1
434.6
TCF12R12S-05
7.0
12.2
18.5
26.0
34.6
44.2
55.1
67.0
80.0
94.2
109.5
126.0
143.5
162.2
182.0
202.9
224.9
248.1
272.4
297.8
324.3
352.0
380.7
410.6
TCF12R14S-05
6.6
11.5
17.5
24.7
32.9
42.3
52.7
64.2
76.9
90.6
105.4
121.4
138.4
156.6
175.8
196.1
217.6
240.1
263.8
288.5
314.3
341.3
369.3
398.5
TCF12R12L-12
4.9
8.3
12.2
16.8
22.0
27.8
34.3
41.3
49.0
57.2
66.1
75.6
85.7
96.4
107.8
119.7
132.2
145.4
159.2
173.6
188.6
204.2
220.4
237.3
TCF12R14L-12
4.4
7.5
11.1
15.3
20.2
25.5
31.5
38.1
45.2
52.9
61.2
70.1
79.6
89.6
100.2
111
.4
123.2
135.6
148.5
162.0
176.1
190.8
206.1
221.9
TCF12R16L-12
4.0
6.9
10.3
14.3
18.8
23.9
29.6
35.8
42.6
49.9
57.8
66.2
75.2
84.8
94.9
105.6
116.8
128.7
141.0
153.9
167.4
181.4
196.0
21
1.2
TCF12R18L-13
3.6
6.2
9.4
13.1
17.3
22.0
27.3
33.1
39.5
46.4
53.8
61.7
70.2
79.2
88.8
98.9
109.5
120.7
132.3
144.6
157.3
170.6
184.4
198.8
TCF12R20L-13
3.4
5.9
9.0
12.5
16.6
21.2
26.3
32.0
38.2
44.9
52.1
59.9
68.1
76.9
86.3
96.1
106.5
117.4
128.8
140.8
153.2
166.2
179.8
193.8
TCF1
1X06S-07
18.9
33.6
51.8
73.5
98.7
127.3
159.5
195.2
234.3
276.9
323.1
372.7
425.8
482.4
542.5
606.0
673.1
743.7
817.7
895.3
976.3
1060.9
1148.9
1240.4
TCF1
1X08S-07
16.2
29.2
45.7
65.4
88.5
114.9
144.7
177.8
214.2
254.0
297.1
343.5
393.3
446.4
502.8
562.6
625.7
692.2
761.9
835.1
91
1.5
991.3
1074.4
1160.9
TCF1
1X06L-1
1
14.0
24.2
36.5
50.9
67.5
86.1
106.9
129.7
154.7
181.8
21
1.0
242.4
275.8
31
1.4
349.1
388.9
430.8
474.8
520.9
569.2
619.6
672.0
726.6
783.3
TCF1
1X08L-08
8.2
14.3
21.7
30.4
40.5
51.8
64.5
78.5
93.8
110.5
128.5
147.7
168.4
190.3
213.5
238.1
264.0
291.2
319.8
349.6
380.8
413.3
447.1
482.2
TCF1
1X10L-10
8.3
14.6
22.4
31.7
42.4
54.7
68.4
83.5
100.2
118.3
137.9
158.9
181.4
205.4
230.9
257.8
286.3
316.1
347.5
380.3
414.6
450.4
487.6
526.3
TCF12X08S-09
8.1
13.9
21.0
29.3
38.9
49.6
61.6
74.8
89.2
104.8
121.6
139.7
159.0
179.5
201.2
224.2
248.3
273.7
300.3
328.2
357.2
387.5
419.0
451.7
TCF12X10S-05
7.8
13.5
20.3
28.3
37.5
47.8
59.3
72.0
85.9
100.9
117.1
134.5
153.1
172.8
193.7
215.8
239.0
263.5
289.0
315.8
343.7
372.9
403.1
434.6
TCF12X12S-05
7.0
12.2
18.5
26.0
34.6
44.2
55.1
67.0
80.0
94.2
109.5
126.0
143.5
162.2
182.0
202.9
224.9
248.1
272.4
297.8
324.3
352.0
380.7
410.6
TCF12X14S-05
6.6
11.5
17.5
24.7
32.9
42.3
52.7
64.2
76.9
90.6
105.4
121.4
138.4
156.6
175.8
196.1
217.6
240.1
263.8
288.5
314.3
341.3
369.3
398.5
TCF12X12L-12
4.9
8.3
12.2
16.8
22.0
27.8
34.3
41.3
49.0
57.2
66.1
75.6
85.7
96.4
107.8
119.7
132.2
145.4
159.2
173.6
188.6
204.2
220.4
237.3
TCF12X14L-12
4.4
7.5
11.1
15.3
20.2
25.5
31.5
38.1
45.2
52.9
61.2
70.1
79.6
89.6
100.2
111
.4
123.2
135.6
148.5
162.0
176.1
190.8
206.1
221.9
TCF12X16L-12
4.0
6.9
10.3
14.3
18.8
23.9
29.6
35.8
42.6
49.9
57.8
66.2
75.2
84.8
94.9
105.6
116.8
128.7
141.0
153.9
167.4
181.4
196.0
21
1.2
TCF12X18L-13
3.6
6.2
9.4
13.1
17.3
22.0
27.3
33.1
39.5
46.4
53.8
61.7
70.2
79.2
88.8
98.9
109.5
120.7
132.3
144.6
157.3
170.6
184.4
198.8
TCF12X20L-13
3.4
5.9
9.0
12.5
16.6
21.2
26.3
32.0
38.2
44.9
52.1
59.9
68.1
76.9
86.3
96.1
106.5
117.4
128.8
140.8
153.2
166.2
179.8
193.8
