Tcf - high airflow ec fans, Chillers turbochill™ air cooled and freecool, Te ch ni ca l fr ee c oo l – Airedale TurboChill FreeCool 200kW - 1830kW User Manual
Page 96: Sound data - tcf
96
Chiller Technical Manual 7525355 V1.1.0_04_2013
Chillers
TurboChill™ Air Cooled and FreeCool
Te
ch
ni
ca
l
Fr
ee
C
oo
l
High Airflow EC Fans
Single Octave Sound Levels (dB)
63 Hz
125 Hz
250 Hz
500 Hz
1000 Hz
2000 Hz
4000 Hz
8000 Hz
Overall
[dB(A)]
TCF11R06S-07
Power
94
92
90
82
81
77
78
81
88
Pressure @ 10m
62
59
58
50
49
44
45
49
56
TCF11R08S-07
Power
91
88
87
80
79
75
77
81
86
Pressure @ 10m
58
56
55
47
47
42
45
49
54
TCF11R06L-11
Power
99
98
94
88
87
84
79
80
92
Pressure @ 10m
66
65
61
55
54
52
46
47
60
TCF11R08L-08
Power
98
96
93
86
86
81
78
80
91
Pressure @ 10m
65
63
61
54
53
48
45
47
58
TCF11R10L-10
Power
96
94
92
84
85
79
77
80
90
Pressure @ 10m
63
61
59
51
52
46
44
47
57
TCF12R08S-09
Power
99
97
94
87
86
82
81
84
92
Pressure @ 10m
66
64
61
55
53
50
49
52
60
TCF12R10S-05
Power
97
95
93
85
84
80
81
84
91
Pressure @ 10m
64
62
60
52
51
47
48
51
58
TCF12R12S-05
Power
96
93
92
84
83
79
81
84
90
Pressure @ 10m
63
60
59
51
50
46
47
51
57
TCF12R14S-05
Power
94
92
91
83
83
78
80
84
90
Pressure @ 10m
61
59
57
50
49
45
47
51
56
TCF12R12L-12
Power
100
98
95
89
88
84
81
83
94
Pressure @ 10m
67
65
62
56
55
51
48
50
60
TCF12R14L-12
Power
100
98
96
89
88
83
81
83
93
Pressure @ 10m
67
65
62
55
55
50
47
49
60
TCF12R16L-12
Power
100
97
95
88
88
83
80
83
93
Pressure @ 10m
66
64
62
54
54
49
47
49
59
TCF12R18L-13
Power
100
97
95
88
88
82
80
83
93
Pressure @ 10m
66
64
61
54
54
49
46
49
59
TCF12R20L-13
Power
99
97
95
88
88
82
80
83
93
Pressure @ 10m
65
63
61
54
54
48
46
49
59
Sound Data - TCF
TCF - High Airflow EC Fans
(1) dB(A) is the overall sound level, measured on the A scale.
(2) All sound data measured at nominal conditions: Water in/out 16/10°C at 35°C ambient.
(3) Based on standard unit, for units fitted with optional extras, please contact Airedale.
