Page 97: Tcf - high airflow ec fans
97
Chiller Technical Manual 7525355 V1.1.0_04_2013
Te
ch
nic
al
Chillers
TurboChill™ Air Cooled and FreeCool
Fre
eC
oo
l
Sound Data - TCF
TCF - High Airflow EC Fans
High Airflow EC Fans
Single Octave Sound Levels (dB)
63 Hz
125 Hz
250 Hz
500 Hz
1000 Hz
2000 Hz
4000 Hz
8000 Hz
Overall
[dB(A)]
TCF11X06S-07
Power
90
87
84
79
78
74
77
81
85
Pressure @ 10m
57
54
52
46
46
41
45
49
53
TCF11X08S-07
Power
91
88
85
79
79
74
77
81
86
Pressure @ 10m
58
55
53
47
46
41
45
49
53
TCF11X06L-11
Power
90
87
84
80
82
75
76
80
86
Pressure @ 10m
57
54
51
47
50
43
44
47
54
TCF11X08L-08
Power
91
88
85
80
82
76
76
80
87
Pressure @ 10m
58
55
52
48
50
43
43
47
54
TCF11X10L-10
Power
92
89
86
81
82
76
76
80
87
Pressure @ 10m
59
56
53
48
50
43
43
47
54
TCF12X08S-09
Power
91
88
86
80
80
76
80
84
88
Pressure @ 10m
58
55
53
48
48
44
48
52
55
TCF12X10S-05
Power
92
89
86
81
81
76
80
84
88
Pressure @ 10m
59
56
54
48
48
44
47
51
55
TCF12X12S-05
Power
93
90
87
82
81
77
80
84
88
Pressure @ 10m
60
57
54
48
48
44
47
51
55
TCF12X14S-05
Power
93
90
88
82
81
77
80
84
89
Pressure @ 10m
60
57
54
49
48
43
47
51
55
TCF12X12L-12
Power
93
90
87
83
85
78
79
83
89
Pressure @ 10m
60
57
54
50
52
45
46
50
56
TCF12X14L-12
Power
93
90
88
83
85
79
79
83
89
Pressure @ 10m
60
57
54
50
52
45
46
49
56
TCF12X16L-12
Power
94
91
88
83
85
79
79
83
90
Pressure @ 10m
60
58
55
50
52
45
46
49
56
TCF12X18L-13
Power
95
92
89
84
85
79
79
83
90
Pressure @ 10m
61
58
55
50
52
45
45
49
56
TCF12X20L-13
Power
95
92
89
84
86
79
79
83
90
Pressure @ 10m
61
58
55
50
52
45
45
49
56
(1) dB(A) is the overall sound level, measured on the A scale.
(2) All sound data measured at nominal conditions: Water in/out 16/10°C at 35°C ambient.
(3) Based on standard unit, for units fitted with optional extras, please contact Airedale.
