Page 93: Sound data - tcf tcf - ac fans
93
Chiller Technical Manual 7525355 V1.1.0_04_2013
Te
ch
nic
al
Chillers
TurboChill™ Air Cooled and FreeCool
Fre
eC
oo
l
Sound Data - TCF
TCF - AC Fans
AC
Single Octave Sound Levels (dB)
63 Hz
125 Hz
250 Hz
500 Hz
1000 Hz
2000 Hz
4000 Hz
8000 Hz
Overall
[dB(A)]
TCF11X06S-07
Power
82
83
82
77
77
73
77
81
85
Pressure @ 10m
50
51
49
45
45
41
45
49
52
TCF11X08S-07
Power
83
84
83
78
77
74
77
81
85
Pressure @ 10m
51
52
50
45
45
41
45
49
52
TCF11X06L-11
Power
82
83
81
79
82
75
76
80
86
Pressure @ 10m
50
51
49
46
49
43
44
47
53
TCF11X08L-08
Power
83
84
82
79
82
75
76
80
86
Pressure @ 10m
51
52
50
47
49
43
43
47
53
TCF11X10L-10
Power
84
85
83
80
82
76
76
80
86
Pressure @ 10m
51
52
50
47
49
43
43
47
53
TCF12X08S-09
Power
83
84
83
79
80
76
80
84
87
Pressure @ 10m
51
52
50
47
47
43
48
52
55
TCF12X10S-05
Power
84
85
84
80
80
76
80
84
88
Pressure @ 10m
51
52
51
47
47
43
47
51
55
TCF12X12S-05
Power
85
86
85
80
80
76
80
84
88
Pressure @ 10m
52
53
51
47
47
43
47
51
55
TCF12X14S-05
Power
86
87
85
81
80
76
80
84
88
Pressure @ 10m
52
53
52
47
47
43
47
51
55
TCF12X12L-12
Power
85
86
84
82
85
78
79
83
89
Pressure @ 10m
52
53
51
49
52
45
46
50
56
TCF12X14L-12
Power
86
87
85
82
85
78
79
83
89
Pressure @ 10m
52
53
51
49
51
45
46
49
55
TCF12X16L-12
Power
86
87
85
82
85
78
79
83
89
Pressure @ 10m
53
54
52
49
51
45
45
49
55
TCF12X18L-13
Power
87
88
86
82
85
79
79
83
89
Pressure @ 10m
53
54
52
49
51
45
45
49
55
TCF12X20L-13
Power
87
88
86
83
85
79
79
83
89
Pressure @ 10m
53
54
52
49
51
45
45
49
55
(1) dB(A) is the overall sound level, measured on the A scale.
(2) All sound data measured at nominal conditions: Water in/out 16/10°C at 35°C ambient.
(3) Based on standard unit, for units fitted with optional extras, please contact Airedale.
