67 Chiller Technical Manual 7525355 V1.1.0_04_2013
Te
ch
nic
al
Chillers TurboChill™ Air Cooled and FreeCool
A
ir C
oo
led
Sound Data - TCC
TCC - AC Fans
AC Fans
Single Octave Sound Levels (dB)
63 Hz 125 Hz 250 Hz 500 Hz 1000 Hz 2000 Hz 4000 Hz 8000 Hz
Overall
[dB(A)]
TCC11X04S-01
Power 81 82 81 77 77 73 77 81 85
Pressure @ 10m 49 50 48 44 45 41 45 49 52
TCC11X06S-01
Power 83 84 82 78 77 73 77 81 85
Pressure @ 10m 51 51 50 45 45 41 45 49 52
TCC11X08S-01
Power 84 85 83 78 78 74 77 81 85
Pressure @ 10m 52 52 51 46 45 41 45 49 53
TCC11X06L-02
Power 83 83 82 79 82 75 76 80 86
Pressure @ 10m 50 51 49 47 49 43 44 47 53
TCC11X08L-03
Power 84 85 83 80 82 76 76 80 86
Pressure @ 10m 51 52 50 47 49 43 43 47 53
TCC11X10L-03
Power 85 86 84 80 82 76 76 80 86
Pressure @ 10m 52 53 51 47 49 43 43 47 53
TCC12X08S-04
Power 84 85 84 80 80 76 80 84 88
Pressure @ 10m 52 52 51 47 47 43 48 52 55
TCC12X10S-04
Power 85 86 84 80 80 76 80 84 88
Pressure @ 10m 52 53 52 47 47 43 47 51 55
TCC12X12S-04
Power 86 87 85 81 80 76 80 84 88
Pressure @ 10m 53 53 52 47 47 43 47 51 55
TCC12X14S-04
Power 87 87 86 81 80 77 80 84 88
Pressure @ 10m 53 54 52 48 47 43 47 51 55
TCC12X10L-05
Power 85 86 84 82 85 78 79 83 89
Pressure @ 10m 52 53 51 49 52 45 46 50 56
TCC12X12L-06
Power 86 86 85 82 85 78 79 83 89
Pressure @ 10m 53 53 52 49 52 45 46 50 56
TCC12X14L-06
Power 87 87 85 82 85 78 79 83 89
Pressure @ 10m 53 54 52 49 52 45 46 49 56
TCC12X16L-06
Power 87 88 86 83 85 79 79 83 89
Pressure @ 10m 54 54 52 49 51 45 45 49 56
TCC12X18L-06
Power 88 88 86 83 85 79 79 83 89
Pressure @ 10m 54 55 53 49 51 45 45 49 55
TCC12X20L-06
Power 88 89 87 83 85 79 79 83 89
Pressure @ 10m 54 55 53 49 51 45 45 49 55
(1) dB(A) is the overall sound level, measured on the A scale.
(2) All sound data measured at nominal conditions: Water in/out 13/7°C at 35°C ambient.
(3) Based on standard unit, for units fitted with optional extras, please contact Airedale.
