Page 58: Air c oo led, Technical data
58
Chiller Technical Manual 7525355 V1.1.0_04_2013
Te
ch
ni
ca
l
Chillers
TurboChill™ Air Cooled and FreeCool
A
ir C
oo
led
20
21
22
Mechanical Data
Notes Units
TCC11X06L-02
TCC11X08L-03
TCC11X10L-03
Cooling Duty - AC Fans
(1)
kW
350
385
410
Nom Input -Cooling Only
kW
112.9
113.3
116.3
EER
(2)
3.10
3.40
3.53
ESEER
(3)
4.38
4.69
4.76
SEER
(3)
4.20
4.55
4.63
Nominal Output - Free Cooling
(4)
kW
N/A
N/A
N/A
Ambient when Free Cooling = 100% Nominal DX
(5)
°C
N/A
N/A
N/A
Cooling Duty - EC Fans
(1)
kW
350
385
410
Nom Input -Cooling Only
kW
110.7
110.3
112.4
EER
(2)
3.16
3.49
3.65
ESEER
(3)
4.77
5.28
5.54
SEER
(3)
4.55
5.08
5.33
Nominal Output - Free Cooling
(4)
kW
N/A
N/A
N/A
Ambient when Free Cooling = 100% Nominal DX
(5)
°C
N/A
N/A
N/A
Cooling Duty - High Airflow EC Fans
(1)
kW
N/A
N/A
N/A
Nom Input -Cooling Only
kW
N/A
N/A
N/A
EER
(2)
N/A
N/A
N/A
ESEER
(3)
N/A
N/A
N/A
SEER
(3)
N/A
N/A
N/A
Nominal Output - Free Cooling
(4)
kW
N/A
N/A
N/A
Ambient when Free Cooling = 100% Nominal DX
(5)
°C
N/A
N/A
N/A
Capacity Steps
(6)
%
30-100%
30-100%
30-100%
Dimensions (H x W x L)
mm
2785 x 2200 x 3758
2785 x 2200 x 4890
2785 x 2200 x 6022
Machine Weight
(7)
kg
3510
4325
4940
Operating Weight
(7)
kg
3650
3970
5080
Construction Material
Base: Plain Galvanised Steel, Panels: Galvanised Sheet Steel,
Epoxy Baked Powder Paint, Light Grey (RAL 7035)
Evaporator - Type
Flooded - Shell and Tube Evaporator
Insulation
Class O, UV stable Insulation
Total Max. Water Flow
l/s
50.0
27.7
27.7
Total Min. Water Flow
l/s
16.7
9.2
9.2
Condenser - Type
Epoxy Coated Aluminium Microchannel & Aluminium Fins
Face Area Total
m²
14.2
18.9
23.7
Maximum Airflow - AC Fans
m³/s
26.5
35.3
44.2
Maximum Airflow - EC Fans
m³/s
26.5
35.3
44.2
Maximum Airflow - High Airflow EC Fans
m³/s
N/A
N/A
N/A
Condenser Fan & Motor
Sickle Bladed Axial Fan
Quantity
6
8
10
Diameter
mm
800
800
800
Maximum Speed - AC Fans
rpm
730
730
730
Maximum Speed - EC Fans
rpm
730
730
730
Maximum Speed - High Airflow EC Fans
rpm
N/A
N/A
N/A
Compressor - Type
Turbocor - Oil Free Compressor
Quantity
1
1
1
Capacity Control
Variable Frequency Drive (VFD) for Linear Capacity Modulation
Refrigeration
Single Circuit
Single Circuit
Single Circuit
Refrigerant Pre-charged
R134a
R134a
R134a
Charge (Total) CCT1 + CCT2
kg
170
320
340
Refrigeration Control
Electronic Expansion Valve (EEV)
Water System
Grooved Type Coupling and Pipe Assembly
Water Inlet / Outlet
DN100
DN100
DN100
Water Drain / Bleed - Evap
inch
1/2
1/2
1/2
Water Volume
l
113.8
113.8
113.8
Minimum System Water Volume
(8)
l
1603.1
1752.0
1858.4
Max System Operating Pressure
Barg
10
10
10
Flow Rate
l/s
13.9
15.3
16.3
Pressure Drop
kPa
7.0
34.9
38.9
Technical Data
Mechanical
TCC11X06L-02, TCC11R08L-03, TCC11X10L-03
(1) Based on AC units performance at 13/7°C return/supply temperatures, 35°C ambient, 100% water.
(2) EER = DX cooling output / (compressor input power + fan input power)
(3) ESEER / SEER based upon unit operating at 12 / 7 °C return / supply temperature, 35°C ambient.
(4) Nominal Free Cooling output at 16/10°C return/supply temperatures, 2°C ambient, 20% ethylene glycol.
(5) Ambient temperature that maximum nominal DX duty can be achieved using Free Cooling only.
(6) This is a nominal figure based on full compressor duty, actual turndown depends on both condensing and evaporating temperatures.
(7) Based on standard unit without options, machine weight includes refrigerant charge, operating weight includes refrigerant charge and water volume.
For unit weights with waterside options fitted please contact Airedale.
(8) For minimum system water volume calculation, refer to Design Features & Information - Minimum System Water Volume Calculations.
