72 Chiller Technical Manual 7525355 V1.1.0_04_2013
Chillers TurboChill™ Air Cooled and FreeCool
Te
ch
ni
ca
l
Fr
ee
C
oo
l
33 34 35
Mechanical Data Notes Units TCF11R06S-07 TCF11R08S-07 TCF11R06L-11
Cooling Duty - AC Fans (1) kW 290 300 390
Nom Input -Cooling Only kW 80.9 81.4 122.9
EER (2) 3.58 3.69 3.17
ESEER (3) 4.64 4.72 4.30
SEER (3) 4.51 4.59 4.17
Nominal Output - Free Cooling (4) kW 265.9 322 291
Ambient when Free Cooling = 100% Nominal DX (5) °C 0.7 3 -2.8
Cooling Duty - EC Fans (1) kW 290 300 390
Nom Input -Cooling Only kW 79.6 77.8 119.5
EER (2) 3.64 3.86 3.26
ESEER (3) 5.40 5.74 4.73
SEER (3) 5.19 5.51 4.55
Nominal Output - Free Cooling (4) kW 279.8 335.8 308.7
Ambient when Free Cooling = 100% Nominal DX (5) °C 1.5 3.5 -1.7
Cooling Duty - High Airflow EC Fans (1) kW 290 300 390
Nom Input -Cooling Only kW 78.8 77.1 117.6
EER (2) 3.68 3.89 3.32
ESEER (3) 5.44 5.78 4.78
SEER (3) 5.23 5.55 4.60
Nominal Output - Free Cooling (4) kW 292.9 349 325.5
Ambient when Free Cooling = 100% Nominal DX (5) °C 2.1 4 -0.8
Capacity Steps (6) % 30-100% 30-100% 30-100%
Dimensions (H x W x L) mm 2785 x 2200 x 3758 2785 x 2200 x 4890 2785 x 2200 x 3758
Machine Weight (7) kg 4075 4885 4505
Operating Weight (7) kg 4535 5435 5055
Construction Material
Base: Plain Galvanised Steel, Panels: Galvanised Sheet Steel,
Epoxy Baked Powder Paint, Light Grey (RAL 7035)
Evaporator - Type Flooded - Shell and Tube Evaporator
Insulation Class O, UV stable Insulation
Total Max. Water Flow l/s 25.0 25.0 30.5
Total Min. Water Flow l/s 8.3 8.3 10.0
Condenser - Type Epoxy Coated Aluminium Microchannel & Aluminium Fins
Face Area Total m² 14.2 18.9 14.2
Maximum Airflow - AC Fans m³/s 30.6 40.8 30.6
Maximum Airflow - EC Fans m³/s 34.4 45.9 34.4
Maximum Airflow - High Airflow EC Fans m³/s 38.4 51.1 38.4
Condenser Fan & Motor Sickle Bladed Axial Fan
Quantity 6 8 6
Diameter mm 800 800 800
Maximum Speed - AC Fans rpm 905 905 905
Maximum Speed - EC Fans rpm 1025 1025 1025
Maximum Speed - High Airflow EC Fans rpm 1100 1100 1100
Compressor - Type Turbocor - Oil Free Compressor
Quantity 1 1 1
Capacity Control Variable Frequency Drive (VFD) for Linear Capacity Modulation
Refrigeration Single Circuit
Refrigerant Pre-charged R134a R134a R134a
Charge (Total) CCT1 + CCT2 kg 135 150 195
Refrigeration Control Electronic Expansion Valve (EEV)
Water System Grooved Type Coupling and Pipe Assembly
Water Inlet / Outlet DN100 DN100 DN125
Water Drain / Bleed - Evap inch 1/2 1/2 1/2
Water Volume l 424.4 513.5 0
Minimum System Water Volume (8) l 1784.4 1920.4 1828.9
Max System Operating Pressure Barg 10 10 10
Flow Rate l/s 12.2 12.6 16.4
Pressure Drop kPa 94.6 91.7 106.8
Technical Data - TCF R
Mechanical
TCF11R06S-07, TCF11R08S-07, TCF11R06L-11
(1) Based on FC units performance at 16/10°C return/supply temperatures, 35°C ambient, 20% ethylene glycol.
(2) EER = DX cooling output / (compressor input power + fan input power)
(3) ESEER / SEER based upon unit operating at 12 / 7 °C return / supply temperature, 35°C ambient.
(4) Nominal Free Cooling output at 16/10°C return/supply temperatures, 2°C ambient, 20% ethylene glycol.
(5) Ambient temperature that maximum nominal DX duty can be achieved using Free Cooling only.
(6) This is a nominal figure based on full compressor duty, actual turndown depends on both condensing and evaporating temperatures.
(7) Based on standard unit without options, machine weight includes refrigerant charge, operating weight includes refrigerant charge and water volume.
For unit weights with waterside options fitted please contact Airedale.
(8) For minimum system water volume calculation, refer to Design Features & Information - Minimum System Water Volume Calculations.
