Introduction
Chiller Technical Manual 7525355 V1.1.0_04_2013
Chillers TurboChill™ Air Cooled and FreeCool
Electrical
Pumps
Speed Controllers (AC Fans)
Bus-bar Chamber
Controls
Circuit 2
Compressors 3 & 4
Circuit 1
Compressors 1 & 2
Fans
Controls and Electrical TCC TCF
Leak detection on circuits containing >300kg of refrigerant
● ●
Intelligent head pressure control
● ●
Actuated suction shut off valve
○ ○
Power monitoring
○ ○
Individual mains power isolator for each compressor
● ●
Separate electrical isolation for fans
● ●
Single point isolation for 3 connection of incoming 3-phase and earth mains power supply
● ●
Emergency Stop fitted to controls compartment door
● ●
Circuit breakers for protection of all major unit components
● ●
Phase rotation relay incorporating phase loss protection
● ●
Mains power loss emergency shutdown via ultracap
● ●
●
Standard features
○
Optional features
–
Feature not available
