Chillers TurboChill™ Air Cooled and FreeCool
Te
ch
ni
ca
l
Fr
ee
C
oo
l
45 46
Mechanical Data Notes Units TCF12R18L-13 TCF12R20L-13
Cooling Duty - AC Fans (1) kW 850 900
Nom Input -Cooling Only kW 242.7 257.8
EER (2) 3.50 3.49
ESEER (3) 4.64 4.62
SEER (3) 4.50 4.47
Nominal Output - Free Cooling (4) kW 791.2 864
Ambient when Free Cooling = 100% Nominal DX (5) °C 1 1.4
Cooling Duty - EC Fans (1) kW 850 900
Nom Input -Cooling Only kW 238.9 253.1
EER (2) 3.56 3.56
ESEER (3) 5.45 5.45
SEER (3) 5.22 5.22
Nominal Output - Free Cooling (4) kW 831.9 906.9
Ambient when Free Cooling = 100% Nominal DX (5) °C 1.7 2.1
Cooling Duty - High Airflow EC Fans (1) kW 850 900
Nom Input -Cooling Only kW 236.2 250.5
EER (2) 3.60 3.59
ESEER (3) 5.49 5.49
SEER (3) 5.25 5.25
Nominal Output - Free Cooling (4) kW 870.3 947.5
Ambient when Free Cooling = 100% Nominal DX (5) °C 2.3 2.7
Capacity Steps (6) % 15-100% 15-100%
Dimensions (H x W x L) mm 2785 x 2200 x 10550 2785 x 2200 x 11682
Machine Weight (7) kg 10745 11630
Operating Weight (7) kg 12210 13210
Construction Material
Base: Plain Galvanised Steel, Panels: Galvanised Sheet Steel,
Epoxy Baked Powder Paint, Light Grey (RAL 7035)
Evaporator - Type Flooded - Shell and Tube Evaporator
Insulation Class O, UV stable Insulation
Total Max. Water Flow l/s 74.2 74.2
Total Min. Water Flow l/s 24.7 24.7
Condenser - Type Epoxy Coated Aluminium Microchannel & Aluminium Fins
Face Area Total m² 42.6 47.4
Maximum Airflow - AC Fans m³/s 91.7 101.9
Maximum Airflow - EC Fans m³/s 103.3 114.8
Maximum Airflow - High Airflow EC Fans m³/s 115.1 127.9
Condenser Fan & Motor Sickle Bladed Axial Fan
Quantity 18 20
Diameter mm 800 800
Maximum Speed - AC Fans rpm 905 905
Maximum Speed - EC Fans rpm 1025 1025
Maximum Speed - High Airflow EC Fans rpm 1100 1100
Compressor - Type Turbocor - Oil Free Compressor
Quantity 2 2
Capacity Control Variable Frequency Drive (VFD) for Linear Capacity Modulation
Refrigeration Single Circuit
Refrigerant Pre-charged R134a R134a
Charge (Total) CCT1 + CCT2 kg 430 430
Refrigeration Control Electronic Expansion Valve (EEV)
Water System Grooved Type Coupling and Pipe Assembly
Water Inlet / Outlet DN150 DN150
Water Drain / Bleed - Evap inch 1/2 1/2
Water Volume l 1365.4 1478.2
Minimum System Water Volume (8) l 3358.5 3588.5
Max System Operating Pressure Barg 10 10
Flow Rate l/s 35.7 37.8
Pressure Drop kPa 108.3 116.8
Technical Data
Mechanical
TCF12R18L-13, TCF12R20L-13
(1) Based on FC units performance at 16/10°C return/supply temperatures, 35°C ambient, 20% ethylene glycol.
(2) EER = DX cooling output / (compressor input power + fan input power)
(3) ESEER / SEER based upon unit operating at 12 / 7 °C return / supply temperature, 35°C ambient.
(4) Nominal Free Cooling output at 16/10°C return/supply temperatures, 2°C ambient, 20% ethylene glycol.
(5) Ambient temperature that maximum nominal DX duty can be achieved using Free Cooling only.
(6) This is a nominal figure based on full compressor duty, actual turndown depends on both condensing and evaporating temperatures.
(7) Based on standard unit without options, machine weight includes refrigerant charge, operating weight includes refrigerant charge and water volume.
For unit weights with waterside options fitted please contact Airedale.
(8) For minimum system water volume calculation, refer to Design Features & Information - Minimum System Water Volume Calculations.
