Mechanical Data Notes Units TCF12R12L-12 TCF12R14L-12 TCF12R16L-12
Cooling Duty - AC Fans (1) kW 670 750 800
Nom Input -Cooling Only kW 198.0 216.0 226.6
EER (2) 3.38 3.47 3.53
ESEER (3) 4.55 4.63 4.65
SEER (3) 4.41 4.48 4.51
Nominal Output - Free Cooling (4) kW 557.6 642.2 717.4
Ambient when Free Cooling = 100% Nominal DX (5) °C -0.8 -0.3 0.4
Cooling Duty - EC Fans (1) kW 670 750 800
Nom Input -Cooling Only kW 194.9 213.0 223.3
EER (2) 3.44 3.52 3.58
ESEER (3) 5.20 5.34 5.42
SEER (3) 4.98 5.11 5.20
Nominal Output - Free Cooling (4) kW 589.2 677.8 755.7
Ambient when Free Cooling = 100% Nominal DX (5) °C 0.1 0.5 1.2
Cooling Duty - High Airflow EC Fans (1) kW 670 750 800
Nom Input -Cooling Only kW 192.4 210.4 220.8
EER (2) 3.48 3.57 3.62
ESEER (3) 5.24 5.37 5.46
SEER (3) 5.02 5.15 5.23
Nominal Output - Free Cooling (4) kW 619.1 711.4 791.7
Ambient when Free Cooling = 100% Nominal DX (5) °C 0.8 1.2 1.9
Capacity Steps (6) % 15-100% 15-100% 15-100%
Dimensions (H x W x L) mm 2785 x 2200 x 7154 2785 x 2200 x 8286 2785 x 2200 x 9418
Machine Weight (7) kg 8215 9075 9960
Operating Weight (7) kg 9285 10295 11295
Construction Material
Base: Plain Galvanised Steel, Panels: Galvanised Sheet Steel,
Epoxy Baked Powder Paint, Light Grey (RAL 7035)
Evaporator - Type Flooded - Shell and Tube Evaporator
Insulation Class O, UV stable Insulation
Total Max. Water Flow l/s 70.3 70.3 70.3
Total Min. Water Flow l/s 23.3 23.3 23.3
Condenser - Type Epoxy Coated Aluminium Microchannel & Aluminium Fins
Face Area Total m² 28.4 33.2 37.9
Maximum Airflow - AC Fans m³/s 61.2 71.3 81.5
Maximum Airflow - EC Fans m³/s 68.9 80.4 91.8
Maximum Airflow - High Airflow EC Fans m³/s 76.7 89.5 102.3
Condenser Fan & Motor Sickle Bladed Axial Fan
Quantity 12 14 16
Diameter mm 800 800 800
Maximum Speed - AC Fans rpm 905 905 905
Maximum Speed - EC Fans rpm 1025 1025 1025
Maximum Speed - High Airflow EC Fans rpm 1100 1100 1100
Compressor - Type Turbocor - Oil Free Compressor
Quantity 2 2 2
Capacity Control Variable Frequency Drive (VFD) for Linear Capacity Modulation
Refrigeration Single Circuit Single Circuit Single Circuit
Refrigerant Pre-charged R134a R134a R134a
Charge (Total) CCT1 + CCT2 kg 405 420 440
Refrigeration Control Electronic Expansion Valve (EEV)
Water System Grooved Type Coupling and Pipe Assembly
Water Inlet / Outlet DN150 DN150 DN150
Water Drain / Bleed - Evap inch 1/2 1/2 1/2
Water Volume l 699.6 819.2 1251.2
Minimum System Water Volume (8) l 2270.6 2577.8 3127.0
Max System Operating Pressure Barg 10 10 10
Flow Rate l/s 28.2 31.5 33.6
Pressure Drop kPa 86.4 97.7 103.8
Technical Data
Mechanical
TCF12R12L-12, TCF12R14L-12, TCF12R16L-12
(1) Based on FC units performance at 16/10°C return/supply temperatures, 35°C ambient, 20% ethylene glycol.
(2) EER = DX cooling output / (compressor input power + fan input power)
(3) ESEER / SEER based upon unit operating at 12 / 7 °C return / supply temperature, 35°C ambient.
(4) Nominal Free Cooling output at 16/10°C return/supply temperatures, 2°C ambient, 20% ethylene glycol.
(5) Ambient temperature that maximum nominal DX duty can be achieved using Free Cooling only.
(6) This is a nominal figure based on full compressor duty, actual turndown depends on both condensing and evaporating temperatures.
(7) Based on standard unit without options, machine weight includes refrigerant charge, operating weight includes refrigerant charge and water volume.
For unit weights with waterside options fitted please contact Airedale.
(8) For minimum system water volume calculation, refer to Design Features & Information - Minimum System Water Volume Calculations.
