Airedale TurboChill FreeCool 200kW - 1830kW - Manual (Page 16)

16
Introduction
Chiller Technical Manual 7525355 V1.1.0_04_2013
Chillers TurboChill™ Air Cooled and FreeCool
Unit Components
Refrigeration
Refrigeration TCC TCF
Compressors - Turbocor Centrifugal ● ●
Dual Maintainable Pressure Relief Valves ● ●
Microchannel Epoxy Coated Condensing Coils ● ●
RTPF Free Cooling Coils - ●
Epoxy Coated RTPF Free Cooling Coils - ○
Actuated Starting Line Assembly ● ●
Filter Driers with Replaceable Cores ● ●
Electronic Expansion Valves ● ●
Flooded Evaporator with integral subcooler ● ●
Stainless Steel Suction Pipe Assembly ● ●
Full Operating Charge of R134a ● ●
Acoustically Lined Compressor Enclosure(s) ● ●
Liquid and Discharge Shut Off Valves ● ●
Liquid Line Sight Glasses (integral to EEV) ● ●
Micro-Plate Economiser ○ ○
Actuated Suction Ball Valve(s)* ○ ○
Liquid level control valve (LLCV) ● ●
Full operating charge of R134a ● ●
Large capacity filter drier(s) with replaceable cores ● ●
Liquid line sight glasses ● ●
Low pressure switch with auto reset ● ●
2 High pressure switches with manual reset per compressor ● ●
High ambient starting valves ● ●
Suction and liquid pressure transducers ● ●
Discharge check (non return) valve(s) ● ●
●
Standard features
○
Optional features
–
Feature not available
CAUTION
* Feature required if unit is to be shut down for winter with water still circulating through unit. Freeze protection.
This is to stop potential liquid migration.
