Introduction
Chillers
TurboChill™ Air Cooled and FreeCool
Range Layout
Model
Nominal
Cooling (kW) EER ESEER
Free Cooling (kW)
Free Cooling EER
Sound
Pressure @
10m (dBA)
Dimensions H x W x L
(mm)
TCF11R06S-07
290
3.70 5.36
279.8
20.01
53.5
2785 x 2200 x 3758
TCF11R08S-07
300
3.91 5.69
335.8
18.01
52.6
2785 x 2200 x 4890
TCF11R06L-11
390
3.32 4.73
308.7
22.08
56.7
2785 x 2200 x 3758
TCF11R08L-08
425
3.47 5.00
386.2
20.72
55.5
2785 x 2200 x 4890
TCF11R10L-10
450
3.67 5.28
453.4
19.46
54.4
2785 x 2200 x 6022
TCF12R08S-09
470
3.39 5.11
399.4
21.42
57.4
2785 x 2200 x 4890
TCF12R10S-05
500
3.67 5.40
472.3
20.27
56.2
2785 x 2200 x 6022
TCF12R12S-05
530
3.80 5.51
540.0
19.31
55.4
2785 x 2200 x 7154
TCF12R14S-05
560
3.89 5.60
604.5
18.53
54.8
2785 x 2200 x 8286
TCF12R12L-12
670
3.43 5.13
589.2
21.07
58.2
2785 x 2200 x 7154
TCF12R14L-12
750
3.55 5.25
677.8
20.78
57.7
2785 x 2200 x 8286
TCF12R16L-12
800
3.63 5.34
755.7
20.27
57.2
2785 x 2200 x 9418
TCF12R18L-13
850
3.63 5.36
831.9
19.83
56.8
2785 x 2200 x 10550
TCF12R20L-13
900
3.62 5.37
906.9
19.46
56.5
2785 x 2200 x 11682
Model
Nominal
Cooling (kW) EER ESEER
Free Cooling (kW)
Free Cooling EER
Sound
Pressure @
10m (dBA)
Dimensions H x W x L
(mm)
TCF11X06S-07
250
3.82 5.33
223.5
45.63
52.4
2785 x 2200 x 3758
TCF11X08S-07
260
4.07 5.73
274.8
42.07
52.1
2785 x 2200 x 4890
TCF11X06L-11
350
3.14 4.59
245.2
50.04
53.3
2785 x 2200 x 3758
TCF11X08L-08
385
3.48 5.01
311.0
47.62
53.2
2785 x 2200 x 4890
TCF11X10L-10
410
3.79 5.30
370.7
45.40
53.2
2785 x 2200 x 6022
TCF12X08S-09
430
3.24 5.22
320.4
49.06
54.8
2785 x 2200 x 4890
TCF12X10S-05
460
3.63 5.46
383.8
47.01
54.7
2785 x 2200 x 6022
TCF12X12S-05
490
3.83 5.61
444.2
45.34
54.7
2785 x 2200 x 7154
TCF12X14S-05
520
3.96 5.69
502.8
43.99
54.6
2785 x 2200 x 8286
TCF12X12L-12
630
3.24 5.18
477.7
48.76
55.6
2785 x 2200 x 7154
TCF12X14L-12
710
3.43 5.28
552.3
48.31
55.5
2785 x 2200 x 8286
TCF12X16L-12
760
3.58 5.38
619.8
47.44
55.4
2785 x 2200 x 9418
TCF12X18L-13
810
3.63 5.43
686.4
46.71
55.3
2785 x 2200 x 10550
TCF12X20L-13
860
3.66 5.45
752.3
46.07
55.2
2785 x 2200 x 11682
Regular Quiet - Single Circuit - FreeCool
Extra Quiet - Single Circuit - FreeCool
