Page 110: General arrangement
110
Chiller Technical Manual 7525355 V1.1.0_04_2013
In
st
alla
tio
n
Chillers
TurboChill™ Air Cooled and FreeCool
OPTIONAL EXTENDED DISCHARGE PLENUM
STANDARD DISCHARGE PLENUM
3 PHASE
MAINS
ELECTRICAL
ISOLATOR
FANS
ELECTRICAL
ISOLATOR
EMERGENCY
STOP
DISCHARGE AIR
CP1
CP2
(Optional)
MAINS
CONTROLS
BUSBAR
CHAMBER
8 - 20 DIA MOUNTING HOLES
IN BASE OF UNIT
(OPTIONAL)
PUMPS
ELECTRICAL
ISOLATOR
2100
500
2200
50
50
439
1520
1131
1520
2793
802
50
4890
280
624
1063
3464
L1
L2
R1
R2
L3
R3
L4
R4
2
1
OPTIONAL EXTENDED DISCHARGE PLENUM
STANDARD DISCHARGE PLENUM
3 PHASE
MAINS
ELECTRICAL
ISOLATOR
FANS
ELECTRICAL
ISOLATOR
EMERGENCY
STOP
DISCHARGE AIR
CP1
MAINS
CONTROLS
BUSBAR
CHAMBER
6 - 20 DIA MOUNTING HOLES
IN BASE OF UNIT
1063
624
2332
802
3758
2793
500
440
1520
1519
279
50
2200
50
2100
50
L1
L2
R1
R2
L3
R3
2
1
6 Fan
8 Fan
Installation Data
General Arrangement
