Page 90
7.7
KEW6305
7-4 Changing displays
Displays can be changed as follows with the
Cursor
keys. The parameters displayed vary depending on
each wiring configuration chosen. Each calculated parameter, although not displayed on the screen, is
actually being computed.
● Changing the display (Three-phase 4-wire configuration)
Screen1
Screen2
Screen3
Screen4
Upper
：
TIME
Middle
：
WP
Lower
：
WS
Upper
：
TIME
Middle
：
WP1
Lower
：
WS1
Upper
：
TIME
Middle
：
WP2
Lower
：
WS2
Upper
：
TIME
Middle
：
WP3
Lower
：
WS3
