11.1
KEW6305
11. Other functions
11.1 Getting power from measured lines
When there is difficulties in getting power from an outlet, KEW6305 operates with powers on the
measured line by using Voltage test leads with Power supply adapter MODEL8312.
Connect the Adapter according to following procedure.
1
Confirm that the Adapter is off.
2
Connect the Plug of the Adapter to VN and V1
terminals on KEW6305 and Power Plug to the
Power connector respectively.
3 Connect the Voltage test leads to VN and V1
terminals of the Adapter.
4 Connect the Alligator clips of the Voltage test
leads to the circuit under test.
5 Power
on
the
Adapter.
6 Power
on
KEW6305.
* Reversed procedure is applied to remove the
Adapter from KEW6305.
Fuse rating : AC500mA/ 600V,
Fast acting, Φ6.3 x 32mm
For further details, refer to the Instruction manual for MODEL 8312.
1
2
3
4
5
6
