KEW6305
5.2
5.2 Basic wiring configurations
● Wiring method for single-phase 2-wire (1ch) “1P2W (1ch)”
● Wiring method for single-phase 2-wire (2ch) “1P2W (2ch)”
● Wiring method for single-phase 2-wire (3ch) “1P2W (3ch)”
VN
V1
A1
N
L
Load
Source
VN
V1
A3
A2
N
L
Load１
Load２
Load 3
A1
Source
VN
V1
A2
A1
N
L
Load１
Load２
Source
