KEW6305
6.16
● Active power P/ Reactive power Q/ Apparent power S
: P1 / P2 / P3, Q1 / Q2 / Q3, S1 / S2 / S3 , max 4 digits
: P, Q, S (total), max 5 digits
Power (*) x VT ratio x CT ratio x 120% Digit & Decimal point position
0.0030 ～ 0.0099 W / Var / VA 0.0099 W / Var / VA
0.0100 - 0.0999 W / Var / VA 0.0999 W / Var / VA
0.1000 - 0.9999 W / Var / VA 0.9999 W / Var / VA
1.000 - 9.999 W / Var / VA 9.999 W / Var / VA
10.00 - 99.99 W / Var / VA 99.99 W / Var / VA
100.0 - 999.9 W / Var / VA 999.9 W / Var / VA
1.000k - 9.999k W / Var / VA 9.999 k W / Var / VA
10.00k - 99.99k W / Var / VA 99.99 k W / Var / VA
100.0k - 999.9k W / Var / VA 999.9 k W / Var / VA
1.000M - 9.999M W / Var / VA 9.999 M W / Var / VA
10.00M - 99.99M W / Var / VA 99.99 M W / Var / VA
100.0M - 999.9M W / Var / VA 999.9 M W / Var / VA
1.000G - 9.999G W / Var / VA 9.999 G W / Var / VA
10.00G - 99.99G W / Var / VA 99.99 G W / Var / VA
100.0G - 999.9G W / Var / VA 999.9 G W / Var / VA
1000G - 180000G W / Var / VA 1800000G W / Var / VA
* The table shows values of power corresponding to each voltage and current range.
Current range Voltage
range 1.000A 2.000A 4.000A 5.000A 10.00A 20.00A 25.00A 40.00A
150.0V 150.0 300.0 600.0 750.0 1.500k 3.000k 3.750k 6.000k
300.0V 300.0 600.0 1.200k 1.500k 3.000k 6.000k 7.500k 12.00k
600.0V 600.0 1.200k 2.400k 3.000k 6.000k 12.00k 15.00k 24.00k
50.00A 100.0A 200.0A 250.0A 300.0A 500.0A 1000A 3000A
150.0V 7.500k 15.00k 30.00k 37.50k 45.00k 75.00k 150.0k 450.0k
300.0V 15.00k 30.00k 60.00k 75.00k 90.00k 150.0k 300.0k 900.0k
600.0V 30.00k 60.00k 120.0k 150.0k 180.0k 300.0k 600.0k 1.800G
The above listed power values apply to single-phase 2-wire(1ch).The power for a single-phase
2-wire(2ch)/single-phase 3-wire/ three-phase 3-wire system will be twice that of the above values.
Total power of the individual phases of a single-phase 2-wire(3ch)/ three-phase 4-wire system will be
three times that of the above values.
● Power factor PF: PF (whole system), PF1/PF2/PF3 (each phase), 4 digits
Display range
-1.000 - 1.000 PF
● Frequency f: 3 digits
Display range
40.0 - 70.0 Hz
● Neutral current In (A) (only for three-phase 4-wire system): max 5 digits
Decimal point and the unit are same as for Current.
