4.2 Setting procedure of each setting item
“ Setting 01” Wiring system
Following explains how to make settings for wiring system.
Select the appropriate wiring system according to the environment to be measured.
Setting item
1P2W(1ch) : Single-phase 2-wire (1ch)
1P2W(2ch) : Single-phase 2-wire (2ch)
1P2W(3ch) : Single-phase 2-wire (3ch)
1P3W : Single-phase 3-wire
3P3W : Three-phase 3-wire
3P3W3A : Three-phase 3-wire
3P4W : Three-phase 4-wire
Default value (or after system reset) 3P3W
* Two-wattmeter method should be used for measuring 3P3W that requires using two Clamp sensors.
* For measuring/ recording the voltage and current on each phase, select “3P3W3A” and use three
Clamp sensors.
1 Use the Cursor key on the selection screen, and select “Setting 01”.
2 Press the ENTER key to get the instrument into setting change mode.
3 Present setting (or default value: 3P3W) blinks. Select the appropriate wiring configuration with the
Cursor key, and then press the ENTER key after making necessary change.
