6.2 Selecting/changing the display screen
The display screens are classified as follows. Following table is also used in
section “6-3 Customizing the display”.
Screen A Screen B Screen C Screen D Screen E Screen F Screen G
Screen 1
Screen
1-A
Screen
1-B
Screen
1-C
Screen
1-D
－ － －
Screen 2
Screen
2-A
Screen
2-B
Screen
2-C
Screen
2-D
－ － －
Screen 3
Screen
3-A
Screen
3-B
Screen
3-C
Screen
3-D
Screen
3-E
Screen
3-F
Screen
3-G
* In case of single-phase 2-wire (1ch), the following screens do not appear:
1-B, 1-C, 1-D, 2-B, 2-C, 2-D
* In case of single-phase 2-wire (2ch), single-phase 3-wire andthree-phase 3-wire, the
following screens do not appear:
1-D and 2-D
● Selecting the display screens
Upon turning the Function Switch from “OFF” to W range, Screen 1-A is displayed. Use the
Cursor keys to select other screens.
Selects from Screen A to G.
Selects from Screen 1 to 3.
NOTE
Turning off the instrument or changing the wiring configuration (“Setting 01”) on SET UP range
returns screen 1-A.
