Part A System installation and start-up Sect. 2.7
05/2003 IFC 110 F 25
2.7 Standard factory settings
• All operating data are set at the factory in accordance with the specifications contained in the
order.
• If no specifications are made in the order, instruments will be delivered with the standard
parameters and functions indicated in the table below.
• To facilitate the start-up of the instrument, current and pulse outputs are set to handle
measurements in ”two flow directions” so that the current flow rates and volumes are displayed
and/or counted independent of the direction of flow. The figures displayed may have a
preceding sign.
• Such factory setting of current and pulse outputs may lead to measuring errors, particularly
when volumes are metered and totalized.
• If e.g. pumps are switched off and ”backflows” occur which are not within the low-flow cutoff
(SMU) range, or if separate displays and counts are required for both flow directions.
• To avoid faulty measurements, it may therefore be necessary to change the setting of the
following functions:
- SMU low-flow cutoff Fct. 1.03, Section 5.3
- display Fct. 1.04, Section 5.5
- current output I Fct. 1.05, Section 5.6
- pulse output P Fct. 1.06, Section 5.7
• For special applications, such as pulsating flows, see Sections 6.5 to 6.10
Standard factory settings
Fct. No. Function Setting Fct. No. Function Setting
1.01 Full-scale range See instr. nameplate 1.08 Status output A2 ON
of flow sensor 1.09 Status output D1 All error
1.02 Time constant 3 Sec. for display, 1.10 Status output D2 Indication F/R
pulse, current and 1.11 Control input C1 Totalizer reset
status ouputs 1.12 Control input C2 OFF
1.03 Low-flow cutoff ON: 1% 3.01 Language German
OFF: 2% 3.02 Flow sensor
1.04 Display meter size See instr. nameplate
flow rate m³/h direction of flow + direction,
totalizer m³ see arrow on
1.05 Current output I
active
flow sensor
function 2 directions 3.04 Entry code NO
range 4-20 mA 3.05 User unit Liter/h
error detection 22 mA 3.06 Application
1.06 Pulse output P flow steady
function 2 directions empty pipe NO
pulse value 1000 pulses/Sec. ADC gain automatic
pulse width symmetric special filter OFF
1.07 Pulse output 2, A1 3.07 Hardware
function 2 directions terminal A1 pulse output A1
pulse value 1 pulse/s selfcheck NO
pulse width 50 ms
